An era when silicon defined sonics that were burned in Meris' memory for years… Ottobit Jr. brings those sounds directly to your pedalboard. To call it a bitcrusher would be an insult. The triggered stutter and pitch/filter/crush sequencers take you to side scrolling, coin collecting maze worlds. Add in a resonant low pass that competes with the best analog synths and grandpa SID would be proud.
Features:
- Handcrafted Algorithms
- Variable Sample Rate and Bit Crushing
- Vintage Synth inspired Low-Pass Filter
- Triggered Stutter Effects
- Sequencer module for Pitch, Filter or Decimation pattern sequencing
- Tap Tempo for Sequencer and Stutter
- Stereo input and output
- Switchable input/output headroom level for Guitar, Synthesizer or Line levels
- MIDI in/out over TRS via the EXP jack with compatible MIDI to TRS conversion box (not included)
- Multi-function EXP jack for optional expansion: MIDI, Preset Switch, Expression Pedal or Tap Switch with compatible hardware. (Expansion hardware not included)
- Expression pedal control over all parameters simultaneously
- Presets are available via external 4-Preset switch or MIDI
- Remote Tap Tempo Switch capable via the EXP jack
- Premium analog signal path and 24-bit AD/DA w/32 bit floating point DSP
- Premium Analog Devices JFET input section
- Colour – translucent coat of deep blue over brushed aluminium
- Designed and built in Los Angeles, California U.S.A.
Specifications:
- Conversion: 24bit A/D D/A
- Digital Signal Processing: 32-bit floating, 48000 Hz
- Input Impedance: 1 Meg Ohm
- Signal-to-Noise Ratio: 115 dB
- Frequency Response: 20Hz-20kHz
- Max. Input Level: 9 dBu (instrument level setting), 12.5 dBu (line/synth level setting)
- Power: 9V DC center-negative, 150mA, 2.1mm jack
- Bypass: Selectable True Bypass (Relay) or Analog Buffered Bypass
- Dimensions: 4.25” (W) x 4.5” (D) x 2” (H)
- Weight: 0.41 kg / 14.6 ounces
