WEIGHT LIMIT     102KG
FRAME MATERIAL     ALLOY
FRAME DESCRIPTION     STEP OVER ALLOY 6061 REMOVABLE BATTERY
FRAME STYLE     STEP-OVER
FORK MATERIAL     STEEL
FORK BRAND     SR SUNTOUR
FORK DESCRIPTION     COIL CAST ALLOY XCM32 W/LOCKOUT
FRONT TRAVEL     100MM
DERAILLEUR FRONT     1X
DERAILLEUR REAR     SHIMANO 9 SPEED
GROUPSET     SHIMANO MIXED
SHIFTERS     9 SPEED TRIGGER
BRAKES     TEKTRO HD-M275
BRAKE TYPE     HYDRAULIC DISC BRAKE
ROTOR FRONT     180MM 6 BOLT
ROTOR REAR     160MM 6 BOLT
CRANKSET AND FRONT CHAINRINGS     38T- NW - STEEL, W/SINGLE ALLOY CG 170MM ALLOY ARM
BOTTOM BRACKET     INTEGRATED
CHAIN     KMC 9 SPEED
PEDALS     9/16 RESIN PLATFORM
REAR GEARS     9 SPEED
CASSETTE DESCRIPTION     SHIMANO HG 11-36T
HANDLEBAR     RISER BAR, W: 680MM, R: 20MM, BACKSWEEP :9D, BARBORE: 31.8MM
HANDLEBAR STEM     ADJUSTABLE A HEAD, EXT: 90MM BORE: 31.8MM, ED BOLT, ADJUSTBALE: 0-90 DEGREE
HEADSET     A HEAD,28.6MM,44*44MM,W/15MM RESIN BLACK CONE
GRIPS / BAR TAPE     ERGO HL-G315 L/R:136.5MM, CLOSED END,ALLOY LOCK
SEAT POST     30.9*350MM, W/ALLOY HEAD
SADDLE     SELLE ROYAL ERGO SPORT 4531HEN
FRONT AND REAR HUBS     F: SF-A262F 36H QR 6 BOLT LBB / R: SF-A626R 36H QR 6 BOLT 10MM 135MM LBB
FRONT AND REAR RIMS     RD-H20 27.5"*32H*14G, DOUBLE WALL, F/V W/EYELETS
FRONT AND REAR TYRES     K1153 KENDA XC MULTI-USE TREAD - 27.5" X 2.35"
SPOKE
WHEEL SIZE     27.5" (650B)
FRONT AND REAR LIGHTS     FRONT & REAR 6V LED
FENDER     70MM STEEL PAINTED
ACCESSORIES (KICKSTAND, PANNIER RACK, CHARGER)     KICKSTAND, 42V 2A CHARGER (3 PIN FOR 36V BATTERY), INTEGRATED SINGLE STAY PANNIER RACK (NOT FOR CHILD SEAT USE)
DRIVE UNIT LOCATION     MID DRIVE
DRIVE UNIT DESCRIPTION     ANANDA M81 CANBUS
MOTOR POWER (WATTS)     250
MOTOR TORQUE (NM)     80
BATTERY DESCRIPTION     REMOVABLE 36V RHINO BOTTOM LOAD
BATTERY SIZE (WATT-HOURS)     468
CHARGE TIME (HOURS)     6
DISPLAY     D18 COLOUR BLUETOOTH (CANBUS)
ASSIST MODES     5 MODES
RANGE (KMS)     70
IP RATING     IP54
