KEY FEATURES
- Bosch Active Line motor with 50 Nm for easy handling
- Bosch PowerPack battery with 400 Watt hour capacity
- Range up to 110 km*
- Practical Bosch Purion display
SPECIFICATIONS
| Battery Watt-hours | 500 Wh,400 Wh |
| Bike Typ | No |
| Motor | Bosch Active Line Plus, 36 V / 250 W / 50 Nm |
| Display | Bosch Purion, LCD display with walk assist |
| Battery Ampere hours | 13,4 Ah,11 Ah |
| Battery | Bosch PowerPack Li-Ion 36 V |
| Drive system | Bosch |
| Range | 100 - 150 km |
| Charger | Bosch, 2A |
| Shifting system | Shimano Altus, 8-speed |
| Shifter | Shimano Altus |
| Crankset | aluminium |
| Rear sprocket description | No |
| Brakes | Shimano MT200, hydraulic disc brake |
| Gear Ratio | front: 38, rear: 11-32,- |
| Brake rotors | 180 |
| Headlight | Herrmans MR GO, LED, 20 Lux |
| Taillight | AXA Blueline, LED with stand light |
| Wheelset | No |
| Frame | Bosch V2, aluminium |
| Wheelsize | 28",26" |
| Rims | Concept, with eyelets |
| Fork | SR Suntour NEX, adjustable |
| Fender | plastic, with edge protector |
| Stem | Concept SL, adjustable |
| Kickstand | rear stand |
| Handlebar | Concept Riser,Concept Tour,Tour, Aluminium |
| Permissible Total Weight | 130 kg |
| Saddle | Kalkhoff Sport Comfort |
| Shock | No |
| Seatpost | Patent, suspension |
| Rear derailleur | Shimano Altus |
| Pedals | Aluminium, with anti slip protection and reflector |
| Front Hub | Shimano TX505, QR |
| Bottom Bracket | Integrated in Drive Unit |
| Rear hub | Shimano TX505, QR |
| Tires | Schwalbe Energizer Active Plus, 47-622,Schwalbe Energizer Active Plus, 47-559 |
| Carrier | Tour, aluminium,Comfort, aluminium |
| Bike weight incl. battery in kg. | ca. 25 kg |
| Travel | 50 mm |
| Gear System | derailleur |
| Brake | disc brake |
| Chain | KMC X8 |
| Bike weight incl. battery in kg. | ca. 25 kg |
| Travel Fork | 50 mm |
| Grip Description | Herrmans Click |
