Breaking Boundaries
With the new Bosch Performance Line CX & 750Wh battery, getting there was the easy part - now it's time for the fun! With 170mm/165mm of travel, piggy back shock and burly build, it's ready to give as much as you are.
Where it thrives
Whatever and wherever you didn't think possible
What it's built for
Handling, Traction, Efficiency, Durability
Highlights
- Proportional Response Tuned carbon frame, 165mm travel / RockShox Zeb Select fork, 170mm travel
- Bosch SmartSystem - 750wh battery & Performance CX motor
- Shimano XT/SLX 12-speed drivetrain / Magura MT5 4-piston brakes
Specs
Details
- Platform
- Model NameMoterra Neo Carbon LT 2
- Model CodeC25572U
Frameset
- FrameMoterra Neo Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 160mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1.5” – 1.8” tapered headtube, 18mm two-bolt kickstand mount
- ForkRockShox Zeb Select, Charger RC, 170mm, DebonAir, 15x110mm, 44mm offset
- HeadsetAcros integrated sealed bearing, tapered
- Rear ShockRockShox Deluxe Select , Coil, 2-Pos mode adjust, adjustable rebound
E-System
- Drive UnitBosch Performance Line CX 250W
- BatteryBosch PowerTube, 750Wh
- ChargerBosch 4A
- DisplayBosch Kiox 300 w/ LED remote
Drivetrain
- Rear DerailleurShimano XT
- ShiftersShimano SLX, 12-speed
- ChainShimano SLX, 12-speed
- CrankFSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
- Rear CogsShimano SLX, 10-51, 12-speed
Brakes
- BrakesMagura MT5 4-piston hydraulic disc, Magura MDR-P 220/203mm, 6-bolt rotors
- Brake LeversMagura MT5 Trail HC hydraulic disc
Wheels
- RimsWTB ST i30 TCS, 32h, tubeless ready
- SpokesStainless Steel, 14g
- Tire Size2.6
- Wheel Size29
- Hubs(F) Formula 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
- Tires(F) Maxxis Assegai, 29x2.6", 3C, EXO , tubeless ready, (R) Maxxis DHR II, 27.5x2.6", 3C, EXO , tubeless ready
Components
- HandlebarCannondale 3 Riser, 6061 Alloy, 25mm rise, 8° sweep, 5° rise, 800mm
- StemCannondale 2, 6061 Alloy, 35mm, 0°
- GripsFabric FunGuy
- SaddleFabric Scoop Shallow Sport, steel rails
- SeatpostCannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL)
